Virgin Mixed Bed (MB) Resin
- In stock, ready to ship
This mixed bed deionization resin is a 50:50 volumetric blend of hydrogen-form strong acid cation resin and hydroxide-form Type 1 strong base anion resin. It is intended for general-purpose deionization applications where a pH-balanced mixed bed is not required, including spot-free rinsing, demineralization, and electrical discharge machining (EDM). The resin performs well in high-alkalinity water and is supplied as spherical styrene/DVB beads for use in refillable DI tanks and other deionization systems.
Key Features:
- 50:50 volumetric blend of cation and anion exchange resins
- Hydrogen-form strong acid cation resin
- Hydroxide-form Type 1 strong base anion resin
- Designed for general-purpose deionization applications
- Suitable for spot-free rinse systems, demineralization, and EDM
- Styrene/DVB polymer matrix
- Spherical bead construction
- Performs best with high-alkalinity water
Specs:
- Resin Blend: 50% cation / 50% anion by volume
- Polymer Matrix: Styrene/DVB
- Ionic Form: Hydrogen & Hydroxide (H⁺ / OH⁻)
- Functional Groups: Sulfonic Acid / Trimethylamine
- Physical Form: Spherical beads
- Color: Black / White to Cream
- Particle Size: 16–50 US Mesh (297–1190 μm)
- Fines (<50 mesh / 300 μm): <1%
- Uniformity: Gaussian
- Uniformity Coefficient: 1.60
- Total Exchange Capacity: 0.45 meq/mL
- Moisture Retention: 52–67%
- Maximum Operating Temperature: 140°F (60°C)
- Minimum Bed Depth: 24 in. (61 cm)
- Maximum Pressure Loss: 25 psi (172 kPa)
- Operating pH Range: 2.0–12.0
- Recommended Service Flow Rate: 1–5 gpm/cu. ft. (8–40 BV/h)
- Backwash Expansion: 50–100%
